KAITEC high-end series screw machines
SKY low noise compressor- developed by North America Development Center.Heavy duty design:Direct-coupled drive without gear noise.Centrifugal fan with slow-speed of revolution; variable frequency oil
Category: Air Compressor
Product Description
SKY low noise compressor- developed by North America Development Center.
Heavy duty design:
Direct-coupled drive without gear noise.
Centrifugal fan with slow-speed of revolution; variable frequency oil cooling fan .
Air intake silencer of the shell; air intake silencer of air compressor.
Low noise of KAITEC series is internationally excellent.
The drilling rig uses high efficiency SKY series screw rotor of the latest generation.
It is equipped with large direct-coupled rotor and low speed compressor.
It is featured by high efficiency, low noise, low vibration and high reliability.
It adopts triple design of cylinder and rolling cone bearing whose service life is ≥100, 000 hours.
High precision rotor guarantees performance and reliability.
Super low noise:
Noise value of 132kW KAITEC screw air compressor is only 73dB and such low noise is internationally excellent.
The energy efficiency of each compressor is higher than national energy-saving standard.
Low noise is internationally excellent.
The warranty period of SKY main engine, "heart" of screw air compressor is five years.
It is possible to reduce system pressure and energy consumption by centrally controlling 2 ~ 16 compressors. It is also capable of reducing leakage of compressed air to maintain stable pressure.
Leave a Review
Related Products
KAISHAN LGCY Diesel Portable Screw Air Compressor adopts 0-100% infinitely variable control of Capacity to realize op...
Kaishan high pressure series mobile screw air compressor: saving oil for 100L every day!Triple air filter system / Tr...
Brand: Kaishan
Type: Portable,stationary
Power:Cummins(550hp/404kw)
Yuchai(150hp/118kw-750hp/551kw)...
Technical Parameters of KAITEC KHE Screw Air Compressor
Model
KHE15
KHE18
KHE22
KHE30
KHE37
Capacity / Working pressure
(m3/min /Mpa)
\
3.13/0.7
3.63/0.7
5.01/0.7
6.35/0.7
2.50/0.8
3.10 /0.8
3.58/0.8
4.90/0.8
6.30/0.8
2.2/1.0
2.79/1.0
3.03/1.0
4.05/1.0
5.64/1.0
\
2.25/1.3
2.77/1.3
3.52/1.3
4.01/1.3
Power (kW)
15
18.5
22
30
37
Noise (db)
67
67
67
68
69
Length(mm)
1450
1550
1750
Width(mm)
890
930
1010
Height(mm)
1073
1140
1288
Model
KHE45
KHE55
KHE75
KHE90
Capacity / Working pressure
(m3/min /Mpa)
7.87/0.7
10.15/0.7
14.39/0.7
16.86/0.7
7.75 /0.8
10.00/0.8
14.18/0.8
16.80/0.8
6.41/1.0
8.77/1.0
12.02/1.0
14.80/1.0
5.43/1.3
6.34/1.3
9.80/1.3
11.90/1.3
Power (kW)
45
55
75
90
Noise (db)
70
70
72
72
Length(mm)
2220
2560
Width(mm)
1410
1520
Height(mm)
1720
1820
Model
KHE110
KHE132
KHE160
KHE185
KHE200
Capacity / Working pressure
( M3 /min/Mpa)
21.76/0.7
24.68/0.7
29.49/0.7
34.06/0.7
37.57/0.7
21.55/0.8
24.63/0.8
29.35/0.8
33.56/0.8
37.42/0.8
18.66/1.0
21.35/1.0
25.25/1.0
29.22/1.0
33.28/1.0
16.47/1.3
18.47/1.3
21.12/1.3
25.14/1.3
29.08/1.3
Power (kW)
110
132
160
185
200
Noise (db)
73
73
75
75
76
Length(mm)
3110
3410
Width(mm)
1690
1760
Height(mm)
2070
2140
Model
KHE220
KHE250
KHE280
KHE315
KHE355
KHE400
Capacity / Working pressure
(m3/min /Mpa)
42.92/0.7
46.94/0.7
51.35/0.7
56.79/0.7
66.08/0.7
75.05/0.7
42.29/0.8
46.55/0.8
50.39/0.8
55.95/0.8
65.43/0.8
74.31/0.8
37.11/1.0
41.93/1.0
46.08/1.0
50.08/1.0
55.12/1.0
64.46/1.0
33.00/1.3
36.80/1.3
41.51/1.3
45.62/1.3
49.58/1.3
58.07/1.3
Motor power(KW)
220
250
280
315
355
400
Noise (db)
77
78
78
82
83
83
Length(mm)
3860
4200
Width(mm)
2200
2200
Height(mm)
2240
2240
