ML series anti-explosion mining screw air compressor adopts efficient engine and has many advantages, including advanced structure, high precision, smooth running, low noise, long service life, low ma
Category: Air Compressor
ML series anti-explosion mining screw air compressor adopts efficient engine and has many advantages, including advanced structure, high precision, smooth running, low noise, long service life, low maintenance cost, low fuel consumption, and high efficiency. It is protected from explosion, overload, short circuit, and phase failure; it also has overheat, air filter blocking, oil filter blocking, and oil core blocking alboom, overheat shutdown and other protectors, and triple protection of regulating valve, pressure control valve and safety valve to prevent running under overpressure. The filter element of the oil separator is made of imported fine glass fiber to keep oil content of the compressed air below 3ppm.
Technical Parameters of KAISHAN ML Explosion-proof Screw Air Compressor
Model
MLGF3.6/7-22G
MLGF6/7-37G
MLGF7.6/7-45G
MLG10/8-55G
Capacity m3/min
3.6
6
7.6
10
Working pressureMPa
0.7
0.7
0.7
0.8
Applied voltage (V)
380/660
380/660(660/1140)
380/660(660/1140)
380/660(660/1140)
Main motor powerkW
22
37
45
55
Motor explosion-proof mark
ExdI
ExdI
ExdI
ExdI
Weightkg
1160
1600
1700
2250
Length×width×highmm
2300×960×1330
2730×1100×1400
2940×1200×1480
2940×1200×1480
Gauge mm
600/762/900
600/762/900
600/762/900
600/762/900
Model
MLGF13/7-75G
MLGF16/8-90G
LGF21/8-132G
MLG25/8-160G
Capacitym3/min
13
16
21
25
Working pressureMPa
0.7
0.8
0.8
0.8
Applied voltageV
380/660(660/1140)
380/660(660/1140)
380/660(660/1140)
380/660(660/1140)
Electric control box explosion-proof mark
ExdibI
ExdibI
ExdibI
ExdibI
Motor explosion-proof mark
ExdI
ExdI
ExdI
ExdI
Weightkg
2600
2648
3725
3760
Length×width×highmm
3240×1210×1550
3240×1210×1550
3560×1360×1695
3740×1360×1745
Gauge mm
600/762/900
600/762/900
600/762/900
600/762/900
Model
MLGF30/8-185G
MLGF35/8-200G
MLGF42/8-250G
MLG42/8-250G
Capacitym3/min
30
35
42
42
Working pressureMPa
0.8
0.8
0.8
0.8
Applied voltageV
660/1140
660/1140
660/1140
660/1140
Main motor powerkw
185
200
250
250
Motor explosion-proof mark
ExdI
ExdI
ExdI
ExdI
Weightkg
4235
4255
5860
5860
Length×width×highmm
3850×1430×1850
3850×1430×1850
4450×1600×2000
4300×1600×2000
Gauge mm
600/762/900
600/762/900
600/762/900
600/762/900
Note: Voltage and gauge are agreed by both parties in the contract.
